WCB Cast Steel Swing Check Valve Class150 Flanged End API Standard Non Return Valve for Oil Gas Steam Pipeline

Product Categories
Qingdao Etrany Machinery Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

WCB Cast Steel Swing Check Valve Class150 Flanged End API Standard Non Return Valve for Oil Gas Steam Pipeline

Packing : Netural Standard Export Seaworthy Packing

Body material : WCB

application : General

Delivery Time : 5-10

Brand Name : Etrany

Usage : Oil Gas Water Industrial

media : Gas Water Oil

Size : DN50-DN1200

Color : Customized Color

Connection : Flanged

Working Temperature : -30~350℃

Place of Origin : China

Payment Terms : T/T

Sealing Material : PTFE, FKM, EPDM

warranty : 1 Years

MOQ : 1

Price : $85.70-3,460 / unit

temperature of media : High Temperature, Medium Temperature, Normal Temperature

Model Number : check valves

Product name : Cast Steel Swing Check Valve

customized support : ODM, OEM

power : Hydraulic

Port Size : DN50-DN1500

Working pressure : 150LB,300LB,600LB,900LB,1500LB,2500

MOQ : 1 Piece

Supply Ability : 5000PCS/month

structure : Control

Contact Now

Product descriptions from the supplier

EN:Valve body adopts WCB carbon steel casting, excellent mechanical property, good high temperature & pressure resistance, resistant to thermal deformation.

ANSI Standard Compliance EN:Designed per ANSI B16.5, API 6D standard, Class150 pressure grade, flange dimension fully matches American standard pipeline

Swing Structure Design EN:Swing clapper internal structure, large flow channel, small flow resistance, less medium pressure loss to save pump power consumption.

Opening & Closing Performance EN:Valve clapper swings flexibly relying on medium flow, automatically open/close to prevent medium backflow effectively.

Sealing Performance EN:Metal hard seal design, wear-resistant sealing face, tight shut-off, suitable for high temp steam, oil & gas with tiny solid impurities.

Bolted Bonnet EN:Bolt-connected bonnet with lifting lug design, convenient to disassemble for internal maintenance without cutting pipeline.

Working Condition Range EN:Class150 rated pressure, suitable for working temperature up to 425℃, widely for high temp industrial working conditions.

Full Size Range EN:Complete specification from NPS2~NPS24(DN50-DN600), Class150/300/600 multi pressure class optional.

Application Medium & Industry EN:Fit for water, steam, crude oil, natural gas, petrochemical medium; used in petroleum, chemical, power plant, heating industry.

Strict Pressure Test EN:All valves pass shell hydro test & sealing test as per API standard, zero leakage before delivery.

Flange & sealing surface CNC precision machining, flatness controlled strictly to ensure flange installation tightness.

Custom Support EN:Customizable: CF8/CF8M stainless steel material, Class300/600 high pressure, special connection end as customer drawing.
